What building a GitLab MCP server taught me about GitLab's API

On a licensed test GitLab, my MCP server tried to approve a merge request with the token of the person who had opened it. The instance had “Prevent approval by merge request creator” turned on, so GitLab refused, and it refused with 401 Unauthorized and the exact body it returns for a token that does not exist. The server did what the status code table says and told its user that the GitLab token might be invalid or expired. The token was fine. The table it followed gave a 401 one meaning: “The user isn’t authenticated.”

That server is gitlab-mcp-server, which exposes GitLab’s REST and GraphQL APIs as tools for clients over the Model Context Protocol. To do it, it has to know what every GitLab operation accepts and returns, and there are three places to learn that from. This post is about what happened when I stopped taking two of them at their word and made the third, a running GitLab, the referee.

Three descriptions of one API

The server maps GitLab’s API one operation at a time, and each action carries two obligations: send a request GitLab accepts, and publish what GitLab returns. There are three places to learn both from:

1. The documentation, and the OpenAPI documents GitLab generates from the desc block of each Grape route.
2. client-go, GitLab’s Go SDK, whose structs and option types the server is built on.
3. A running GitLab.

The first two describe the third. People write them, and they drift. In June 2026 a user asked in gitlab-org/api/client-go#2269 whether drift between the API and the client could be detected more deterministically. A maintainer replied that moving to structs generated from the OpenAPI document had been discussed, but that, at least back then, the schema was not comprehensive, and that they knew no great way to detect drift on something like GraphQL. In September I put a number on it in gitlab-org/api/client-go#2300: 897 fields GitLab sends that the library does not model.

None of that is anyone’s failure. A description nobody checks against the thing it describes drifts, and the only way to check is to ask the thing.

Making GitLab the referee

I ended up with five checks. Each sees something the others cannot, and the first three each have a blind spot worth stating, because the first of them hid one of the bugs below.

A record taken from a booted GitLab

cmd/gen_api_live boots a released gitlab-ee image, runs a Ruby script inside it through gitlab-rails runner, and asks the loaded application what its REST API is: every Grape entity with its fields and the condition each is sent under, every route with its parameters and the entity its desc names, and the licensed feature table. The answer is committed as gitlab-api-live.json and every audit reads it offline, so no audit of the REST API has to boot a GitLab, in CI or anywhere else. Taking the record needs no license, because a license gates features when a request is served, not when a class loads. The current one comes from GitLab 19.4.1-ee on 4 October 2026 and holds 596 entities with 7,412 fields and 2,152 routes.

Booting beats parsing. The two records it replaced read text, the generated OpenAPI document and a scan of the Grape source, and measured against GitLab 19.3.1 the instance had 1,935 fields the scan never saw. GeoSiteStatus builds its field list by iterating a constant made from two method calls, so the source says, in effect, “expose the loop variable”: the scan found 26 fields, the instance reports 606.

Blind spot: a route’s response entity comes from its own desc annotation, because that is all a route says about itself before a request is served. When the annotation is wrong, the record is wrong with it (the context commit story below).

An inventory of the requests the tests send

Almost every unit test builds its GitLab client with one helper that wraps the mock server in a recorder: method, templated path (/projects/:project_id/issues/:issue_id/notes), query parameter names, JSON body keys, and for GraphQL the operation and its variables. Merged across the suite, request-inventory.json holds 1,633 rows from 178 packages (committed on 8 October). It exists because no earlier audit looked at the request a handler builds, and the package comment of the audit rule that now reads it says what that cost (all nine were GraphQL requests, which the next check catches):

Read beside client-go’s option structs, the inventory found nine optional parameters that client-go writes into every request body because their struct tags lack omitempty, such as "package_name_pattern": null on every update of a package protection rule. All nine are fixed in gitlab-org/api/client-go!3063, in review on 9 October.

Blind spot: a row is the union of what one package sent to one endpoint, never which names went together, and nothing on the wire names the action.

The GraphQL schema GitLab.com serves

cmd/gen_graphql_schema introspects GitLab.com and commits the schema, 4,475 types from 19.5.0-pre, taken on 27 September 2026, and the same test helper validates every GraphQL request a tool’s unit test sends against it, document and variables. It even walks enum values itself, because the validator library accepted "critical" for VulnerabilitySeverity and GitLab does not. Before the pin, a green GraphQL test only proved that the code agreed with its own fixture: the nine broken tools above were four sending a document the schema refuses and five a value GitLab does not have. On 9 October none of the server’s 39 documents is refused, nor any of the 36 client-go documents it can judge.

Blind spot: query cost, since the check enforces no depth or complexity limit; deprecations, which the pinned schema does not carry; and fields a self-managed release lacks, since GitLab.com runs a pre-release. A weekly CI job boots the latest self-managed image and validates the server’s own documents against it, which covers the last of the three for the newest release.

An audit that joins them, and its declarations

cmd/audit_1to1 holds the server to the SDK and the API rule by rule, the request each handler builds included. Its run of 9 October compared 240 output types with what the record says their endpoints send, and found 2,066 fields GitLab sends that the server does not publish, 1,414 of which client-go does not model either. None is left as noise: a finding that is not the server’s bug is answered in a declaration table with a category and a reason, and a declaration that stops matching anything fails the run. That rule is what retires a declaration once a GitLab release carries the fix, as the section on the register shows.

A Docker end-to-end run

Under all of that, test/e2e/gitlab/ drives the real server binary against an ephemeral GitLab CE or a licensed EE, from 223 test files as of 9 October. The unit checks catch a request that cannot work; only a real instance catches a response the server misreads. The 401 at the top of this post came from here.

What building and checking the server found

Each of these has a row in the register and a merge request to GitLab or client-go. States are as read on 10 October 2026 at 04:48 UTC.

A 401 that meant 403

This is the exchange from the opening, written out as HTTP from the error line the gitlab-mcp-server register entry for this 401 keeps from the licensed end-to-end run, POST /api/v4/projects/109/merge_requests/1/approve: 401 {message: 401 Unauthorized}:

When I read GitLab’s source afterwards, I found thirty places written to refuse with a 401 a user who is already authenticated, all but one through unauthorized!, from merging and approving to mirrors, access tokens and SAML group links. Anyone can reproduce the pattern with read-only requests against gitlab.com and a token that is not a Maintainer of gitlab-org/gitlab. Every 401 below carries the same body, {"message":"401 Unauthorized"}, and every path is under /api/v4:

Changing the status code was not an option, since GitLab’s API style guide counts changing any status code other than 500 as a breaking change. A related GitLab issue, gitlab-org/gitlab#624056 (“Agree a consistent 401 and 403 error shape”), asks for one 401 and 403 error shape across GitLab’s modular feature APIs, such as Orbit and Artifact Registry, and an older report of one of the thirty sites is gitlab-org/gitlab#383531 from 2022. So gitlab-org/gitlab!260774 documents the behavior instead. It merged on 9 October and is already on the REST API troubleshooting page, with a new “Status code 401” section that lists the three cases and the GET /user check. The status table’s row now says it too:

The server now blames the token only when GitLab does: when the body carries the RFC 6750 code invalid_token, or when the 401 came from the GraphQL endpoint, which answers 401 only from its authentication checks. Before its HTTP pool drops a credential over an ambiguous 401, it asks GET /api/v4/user once. That workaround stays until GitLab answers 403 at those thirty sites, and no change proposing that is in review.

Writes answered as successes

A board name GitLab cannot save. Board validates a changed name at 255 characters, and nothing else checks it. A longer or empty name on PUT /projects/:id/boards/:board_id answered 200 OK with the board as it was, every other attribute of the request dropped along with the name. On POST it answered 201 Created with a board whose id was null, and nothing had been created.

{"name": "<256 characters>", "hide_backlog_list": true}

The update’s cause was one line. The board helper was not memoized, so each call loaded a fresh record, and both the validity check and the response read the stored board, valid because its name had not changed. The create helper presented the service’s payload whatever the service said.

-  board_parent.boards.find(params[:board_id])
+  @board ||= board_parent.boards.find(params[:board_id])

gitlab-org/gitlab!260458 memoizes the helper, answers a failed write in both helpers with render_validation_error!, and states the limit on the API pages. The reviewer accepted the changed status as a bug fix, since only a request that was never saved gets the new answer. It merged on 9 October and is live on GitLab.com. I took no workaround, because a length check of my own would copy a validation the pages did not state.

A delete that deletes nothing, and a refusal that looks like an outage. Managing external status checks takes the Maintainer role. A Developer’s delete answered 204 No Content and the check was still there; a Developer’s create answered 500 with {"message":["Not allowed"]}, which a client retries or reports as an outage.

Both had the same root: a refusal from the service that never reached the response. destroy_conditionally! sets the status to 204 before it yields and discards what the block returns, and the create service’s refusal carried no HTTP status, so Grape answered its nil status with 500. GitLab’s own spec only drove an owner, who may manage the checks, and a non-member, whom the route answers 404 before the service runs, so no test of GitLab’s reached the service’s refusal. gitlab-org/gitlab!260486 checks the role with authorize! before calling the service, as the merge request routes of the same file already did, and renders the service’s error inside the delete block, so a failed destroy is now a 422 rather than a 204:

 post do
+  authorize! :create_external_status_check, user_project
 ...
-    destroy_conditionally!(service.external_status_check) do
-      service.execute
+    external_status_check = service.external_status_check
+    authorize! :delete_external_status_check, external_status_check
+
+    destroy_conditionally!(external_status_check) do
+      response = service.execute
+
+      render_api_error!(response.payload[:errors], response.http_status) if response.error?
     end

It merged on 9 October, in milestone 19.6. Until a release carries it, the server reads a 500 carrying “Not allowed” as the role refusal it is, and the delete action’s usage asks the caller to confirm a deletion with the list action, because nothing on the wire tells that 204 apart from a real one.

The route says one entity and sends another

GET /projects/:id/merge_requests/:merge_request_iid/context_commits declared success Entities::Commit and presented Entities::CommitWithLink with type: :full, which adds ten keys: author, author_gravatar_url, commit_url, commit_path, description_html, title_html, signature_html, prev_commit_id, next_commit_id and pipeline_status_path. Grape uses the desc block for documentation only, so the docs page, both OpenAPI documents and anything generated from them described a response without those ten keys, and no test of GitLab’s could notice.

The booted record could not see it either, since it takes the entity from the same annotation. I found it by reading the handler instead of the annotation, while I surfaced the context commit keys for the server. The server publishes four of them from the captured response, and because the record says the route never sends them, each of the four carries a declaration in the audit.

       desc 'List all context commits for a merge request' do
         detail 'Lists all context commits for a specified merge request.'
-        success Entities::Commit
+        success Entities::CommitWithLink
         is_array true

gitlab-org/gitlab!260487 changes that line, regenerates both OpenAPI documents, adds an example request and a complete example response to the merge request context commits API page, and adds a request spec that holds the response’s keys to the documented entity’s exposures, so the two cannot drift apart again. Against master without the annotation change, that spec fails on exactly the ten keys:

it 'returns the attributes of the entity the endpoint documents' do
  route = described_class.routes.find do |r|
    r.request_method == 'GET' && r.path.include?('/merge_requests/:merge_request_iid/context_commits')
  end
  documented_keys = route.options[:entity].root_exposures.map { |exposure| exposure.key.to_s }

  get api("/projects/#{project.id}/merge_requests/#{merge_request.iid}/context_commits", user)

  expect(response).to have_gitlab_http_status(:ok)
  expect(json_response.first.keys).to match_array(documented_keys)
end

It merged on 9 October. Two earlier fixes of the same kind merged in September: gitlab-org/gitlab!254698 for three job token scope endpoints, and gitlab-org/gitlab!254699 for two project group listings.

The approvals endpoints are the same class with a twist. The merge request approvals GET and the approve and unapprove POSTs declare a four-key entity. Community Edition sends those four. Every Enterprise Edition build sends 24, licensed or not, GitLab.com included, because the EE module overrides the presenting helper with no license check. The server itself once trusted the four-key description: in September a Community Edition instance answered those four keys and GitLab’s generated OpenAPI document agreed, so the server cut its output to four. The record taken from an EE image could not correct that, since it reads the same annotation. When I read the same GET on GitLab.com on 5 October, it answered all 24, and the server now reads the other 20 from the captured response.

gitlab-org/gitlab!259766, merged on 9 October, documents both editions on the page. gitlab-org/gitlab!261004, in review, makes the entity and the generated OpenAPI document say 24, as a reviewer asked.

A challenge that was never sent

When a token lacks the scope an endpoint needs, GitLab answers 403 with insufficient_scope in the JSON body and no WWW-Authenticate header. RFC 6750, section 3 asks for the challenge, and the MCP authorization flow reads it to learn which scope to request next. GitLab’s source says as much in lib/api/api_guard.rb:

# FIXME: ForbiddenError (inherited from Bearer::Forbidden of Rack::Oauth2)
# does not include WWW-Authenticate header, which breaks the standard.

This one surfaced while I implemented insufficient-scope detection for the server’s OAuth mode, and it is the clearest case for making GitLab the referee. The obvious implementation, parsing error="insufficient_scope" out of the challenge, would have compiled, passed a hand-written fake that emitted the header, and never once fired against a real GitLab. The server reads the body instead.

gitlab-org/gitlab!260668 writes the challenge from the same parameters as the body, so the two cannot disagree, and after review it names only the scopes that can authorize the request. Every other 403 is unchanged, the fine-grained token one included. It is in review. The server needs nothing from it: this one is a contribution, not a fix I was waiting for.

The SDK half: client-go

Some of what the checks find is in the SDK rather than in GitLab. Two examples.

A whole page fails. GitLab sends a commit’s extended_trailers as a map from each trailer to the list of its values, and client-go declares ExtendedTrailers map[string]string, as it still does in v3.17.0, its newest release as of 9 October 2026. So ListCommits with trailers=true fails as a whole as soon as one commit on the page carries a trailer:

"extended_trailers": {
  "Approved-by": ["<name> <email>", "<name> <email>"],
  "Cc": ["<name> <email>", "<name> <email>"]
}

client-go v3.15.0 to v3.17.0, ExtendedTrailers map[string]string:
  json: cannot unmarshal array into Go struct field .1.extended_trailers.Cc of type string
client-go!3082, ExtendedTrailerValues map[string][]string:
  the page decodes

That error is the one gitlab-org/api/client-go!3082 records for its test page, whose second commit carries two Cc: trailers. The merge request adds ExtendedTrailerValues map[string][]string on the extended_trailers key and deprecates the old field, so no caller stops compiling. Until it ships, the server passes over client-go’s decode error and reads the commits from the response it already received.

A field that never decodes. ImportStatus tags its timestamp create_at while GitLab sends created_at, so it has never been filled. gitlab-org/api/client-go!3085 fixes it and adds fields GitLab sends and accepts that nine other structs miss, such as last_commit on tree entries and raw on pipeline variables. Both are in review.

When the server needs a field client-go does not model, it reads it from the response it already has rather than making a request of its own (ADR-0021); 84 non-test files did this on 9 October. Each gap read that way is recorded in the register with the handler that carries it, and the workaround stays until the server moves to a client-go release that models the field.

From finding to merge request

The gitlab-mcp-server upstream register is one Markdown file in the repository: “Defects and missing capabilities found in projects this server depends on, kept here so they are contributed back rather than only worked around.” Each entry records what the defect is and where, how it was found, the workaround it costs, and the merge request with its state. It is permanent: an entry is never deleted, and when a fix lands it is marked merged with the release that carries it.

Writing a finding down that way, with its evidence and what it costs a client, is most of the work of a merge request already. For a GitLab fix, the loop closes like this:

The context commit fix is the next one through. When cmd/gen_api_live is run against a release that carries gitlab-org/gitlab!260487, the record will hold that route under CommitWithLink, the four declarations will match nothing, the stale-declaration check will fail, and they will be deleted along with the explanation they carried. The six keys the server leaves out will then be reported as keys GitLab sends that the server does not publish, and each will need a declaration of its own, while the four it publishes stay read from the captured response until client-go models them.

The loop has run before. gitlab-org/gitlab!254698, the job token scope fix above, shipped in GitLab 19.4.0, and when the record moved from 19.3.1-ee to 19.4.1-ee, the stale-declaration check failed on the declaration that had answered its findings until it was removed. On the client-go side the loop closes when the server moves to a release that carries the fix, not through the record: register row 34 lists fourteen client-go merge requests that add fields GitLab sends unconditionally. They grew out of the measurement in client-go#2300, all fourteen were merged and released between client-go v3.1.0 and v3.15.0 (9 to 28 September 2026), and each one retired a workaround in the server.

In numbers

As read on 10 October 2026 at 04:48 UTC, for the merge requests the register records as opened between its review of 5 October and 9 October:

The register itself, as it stood on the morning of 9 October, held 102 entries across eight upstream projects (client-go 46, gitlab-org/gitlab 31, one of them shared with client-go, the MCP Go SDK 17 and five smaller ones), and 86 of them had a fix in review or merged, 81 of those mine.

One merge request outside the stories above is worth a line: gitlab-org/gitlab!260459, in review, would make GitLab refuse an unknown filter value on a pipeline’s security findings. An unknown severity answers 500, and a filter made only of unknown report types matches no scan, so an empty page that means “you misspelled the filter” reads as “no vulnerabilities”. The register lists the rest.

Closing

These checks were built to keep one server honest, and most of what they caught was not the server’s to fix. Writing each finding down with its evidence and its workaround is what made it cheap to send upstream, and the speed of the answer was GitLab’s. My thanks to GitLab’s reviewers and technical writers, who took every one of them seriously.

The booted record also carries what each REST route and GraphQL element demands of a fine-grained personal access token, and eight of the 23 merge requests counted above came out of that work. GitLab fine-grained personal access tokens, one action at a time is the next post: it covers that work and ends with how to create a token for the server.

The server’s documentation is at jmrp.io/docs/gitlab-mcp-server, its gitlab-mcp-server upstream contributions are listed on the About page, and the register is on GitHub.
