A Vault File That Fails Closed: Encrypt-then-MAC on an MCU

A password vault has one job at rest: hand back exactly the bytes you stored, or refuse. Not “probably,” not “best effort”: a vault that returns almost your password, or that behaves differently when a file has been tampered with, is worse than no vault at all. On a microcontroller, where the encrypted files live on a flash chip an attacker can desolder and read, “refuse” has to be the default for everything that isn’t provably authentic.

This post is about the file format I use in a hardware password manager I’m building (not yet released), an ESP32-class device that stores credentials on its internal flash. The whole design rests on one rule that is surprisingly easy to get wrong: never decrypt a byte you haven’t authenticated first. Get the order wrong and you’ve built a padding oracle. Get it right and the vault fails closed.

Decrypt-first is a footgun

First, the threat. This is a device you can hold in your hand, and the credentials live on a flash chip soldered to the board. An attacker who steals it isn’t limited to typing PINs at the screen: they can desolder the flash and read it on a bench programmer, or dump it over a debug port, and walk away with the raw ciphertext. From then on the attack is offline: no lockout, no rate limit, all the time in the world. The threat model for the firmware treats raw flash readout as a real possibility (mitigated in production by the ESP32’s own flash encryption), so the file format has to assume the attacker is holding the exact bytes it wrote and is free to modify them and feed them back.

That’s what makes decrypt-first dangerous. The intuitive design is the wrong one: you have ciphertext, you want plaintext, so you decrypt, and only then, maybe, you check whether the result “looks right.” To see why that order is fatal, you have to look at what happens inside.

How does CBC padding become an oracle?

Start with the basics: AES is a block cipher; it only knows how to work on fixed-size chunks, 16 bytes each. Since your data almost never lands on an exact multiple of 16, the last chunk is topped up with filler bytes (the padding) until it fills the block. PKCS#7 does this by a simple rule: if 5 bytes are missing, append five 0x05 bytes; if 11 are missing, eleven 0x0B. When decrypting, the very last thing the algorithm does is look at that padding and check it’s well-formed.

Now the part that makes it dangerous. AES in CBC mode chains the blocks: each ciphertext block is mixed (with an XOR) into the next one’s decryption. Think of a row of dominoes: nudge one and you move its neighbor. That hands the attacker a lever: tamper with one ciphertext block and you control, byte by byte, what comes out of the block after it, including that final padding the decryptor is about to inspect.

And here’s the trap: whether the padding is valid is something the system gives away. If the attacker can tell a “bad padding” failure from any other (a different error message, a log line, or simply a reply that takes a hair longer), they’ve got an oracle: a box they can ask one yes/no question per try, and it always answers truthfully. It’s like a chess opponent who, without meaning to, winces whenever your move helps them: that tell, repeated, is enough to reconstruct the game. With that single “is the padding valid?” bit, asked enough times, they peel the plaintext apart one byte at a time, without ever holding the key:

From Lucky Thirteen to the Doom Principle

That is the padding oracle attack, first described by Serge Vaudenay in 2002, and it has been breaking real protocols for two decades: Lucky Thirteen against TLS in 2013, POODLE against SSL 3.0 in 2014.

Moxie Marlinspike distilled the lesson into The Cryptographic Doom Principle: “if you have to perform any cryptographic operation before verifying the MAC on a message you’ve received, it will somehow inevitably lead to doom.” Decryption is a cryptographic operation. So the MAC check has to come first.

Three ways to combine a cipher and a MAC

Encrypting solves confidentiality (nobody can read the secret) but not integrity (knowing nobody tampered with it along the way). That’s the MAC’s job. Think of it as the wax seal on an old letter: the sender stamps the seal with a signet only they hold (the key), and the recipient checks it’s still intact before opening; if someone intercepted and rewrote the letter, the seal no longer matches and it’s discarded unread. HMAC is that seal in cryptographic form: with a key it produces a short tag from the message, and changing a single byte invalidates it.

Authenticated encryption therefore needs both pieces: a cipher (for confidentiality) and a MAC (for integrity). But there are exactly three ways to bolt them together, and they are not equally safe. The canonical analysis is Bellare and Namprempre’s Authenticated Encryption: Relations among Notions and Analysis of the Generic Composition Paradigm (J. Cryptology, 2008), reinforced for secure channels by Hugo Krawczyk’s The Order of Encryption and Authentication for Protecting Communications.

The three generic compositions

Encrypt-then-MAC is the only one where you can authenticate the message without touching the cipher: the tag is computed over the ciphertext, so checking it requires no decryption. That property is exactly what kills the padding oracle: a tampered file never reaches the decrypt path. So that is what the vault uses.

Put the two orderings side by side and the doom is obvious. The composition isn’t an academic taxonomy; it’s a decision about which step runs first when an attacker hands you bytes:

Same primitives, opposite outcomes

The envelope: 49 bytes of header before the AES-256-CBC ciphertext

Every encrypted record in the vault (each credential, each TOTP secret, each segment of the listing index) is one self-contained envelope. Picture a postal envelope: the outside carries, in the clear, just enough to handle and verify it (the version, the IV, and the tag that acts as the seal), and the encrypted letter rides inside. They all share the same fixed prefix:

The layout above is the whole envelope, but the tag authenticates a little more than the envelope holds. Ahead of the IV and ciphertext, the firmware prepends an 8-byte authenticated context prefix and HMACs the lot (over SHA-256) with the record MAC sub-key:

// authPrefix = ver(1) ‖ recordType(1) ‖ slotId(2, LE) ‖ generation(4, LE)
// authMsg    = authPrefix ‖ iv ‖ cipher
std::array<uint8_t, kEnvelopeContextSize> ctxBuf{};
writeEnvelopeContext(ctxBuf.data(), context);                // 8 B

// The three parts feed one multipart HMAC: no concatenation buffer exists.
VaultCrypto::hmacSha256Parts(macKey, macKeyLen, ctxBuf.data(), ctxBuf.size(),
                             iv, kIvSize, cipher, cipherLen, tagOut.data());

That context prefix is not part of the envelope: the version byte stays 0x01 and the envelope layout doesn’t change a single byte. recordType and slotId come from where the record lives; generation comes from the authenticated meta.bin. Credentials and TOTP entries are stored as entries of an append-only record log, a few segment files of 32 slots each, and every entry header repeats its type, slot and generation in the clear so a scan can find entries without a key. Nothing believes those clear copies: the tag, recomputed with the generation meta.bin holds, decides. So the tag proves that this exact ciphertext, in this exact slot, of this exact type, at this exact revision belongs here, untouched, not just that someone who knew the key produced some ciphertext. Why those three extra fields earn their keep is its own section; first, the basics of writing and reading one.

The IV (initialization vector) is the 16 random bytes that seed CBC’s chaining for the first block; without it, two records with the same first block would decrypt to the same plaintext, leaking equality. The vault draws a fresh IV from the ESP32 hardware RNG on every write, so saving the same password twice produces two completely different ciphertexts: an attacker reading flash can’t even tell that two slots hold the same value. The IV isn’t secret (it’s stored in the clear, right there in the envelope), but it must be unpredictable and unique per write, and authenticating it under the tag stops anyone from quietly substituting one.

Writing a record: encrypt, then MAC

The write path is encrypt-then-MAC in the literal order of its name. The plaintext is first serialized to a packed binary record, always exactly 4,096 bytes (more on that later), then encrypted with AES-256-CBC under the encryption sub-key, then the tag is computed over the ciphertext under the MAC sub-key, and finally the finished envelope is appended to the record log:

// Encrypt-then-MAC, assembled in place as [ver][iv][hmacTag][cipher].
env[kCredVerOffset] = kCredFormatVersion;
bool ok = VaultCrypto::encrypt(keys.enc.data(), plainBuf, plainLen,
                               iv, cipher, &cipherLen);
VaultCrypto::secureWipe(plainBuf, plainLen);
if (ok) ok = computeTag(keys, id, generation, iv, cipher, cipherLen, tagBuf);
std::memcpy(tag, tagBuf.data(), kCredHmacTagSize);
VaultCrypto::secureWipe(tagBuf.data(), tagBuf.size());

// Persist: append the envelope as one record-log entry under its generation.
RecordStore::writeEnvelope(LogEntryType::Credential, id, generation,
                           env, len, offset);
VaultCrypto::secureWipe(env, kCredMaxFileSize);   // the envelope buffer too

Note the wiping. The plaintext, the keys, and the scratch buffers all hold secret material, and on a device that can be powered down and probed, leaving them in RAM is a liability. Every buffer is cleared with a zeroize primitive that the compiler is not allowed to optimize away: mbedtls_platform_zeroize on the device, which exists precisely because a plain memset can be elided as a “dead store.”

Why verify the MAC before decrypting?

Decrypting first exposes a padding oracle: the decrypt step inspects PKCS#7 padding and leaks timing or error differences an attacker can grind offline. Verifying the tag first means no attacker-controlled bytes ever reach the cipher, so a tampered file is rejected without a single byte being decrypted.

The five-step read path

This is the section the whole format exists for. When the vault loads a credential, it does five things in a strict order, and any failure at any step returns nothing:

// Fail-closed: wipe the caller's record up front, so EVERY reject path
// (bad size, version, MAC, decrypt, or decode) leaves no residue behind.
out.wipe();

// 1. Structural checks: plausible size, ciphertext is a whole number of blocks.
if (len < kCredMinFileSize || len > kCredMaxFileSize) return RecordLoad::Rejected;
const size_t cipherLen = len - kCredHeaderSize;
if ((cipherLen % kAesBlockSize) != 0)                 return RecordLoad::Rejected;

// 2. The envelope is [ver][iv][storedTag][cipher]; reject an unknown version.
if (env[kCredVerOffset] != kCredFormatVersion)        return RecordLoad::Rejected;

// 3. Verify-before-decrypt: recompute the tag and compare in CONSTANT TIME.
if (!computeTag(keys, id, generation, iv, cipher, cipherLen, expectedTag))
    return RecordLoad::Unreadable;  // could not compute: says nothing about flash
if (!VaultCrypto::constantTimeEqual(expectedTag.data(), storedTag,
                                    kCredHmacTagSize)) {
    // MAC mismatch → tampered or corrupt. Wipe scratch, produce no plaintext.
    return RecordLoad::Rejected;
}

// 4. Tag verified: only now is it safe to decrypt.
VaultCrypto::decrypt(keys.enc.data(), iv, cipher, cipherLen, plainBuf, &plainLen);

// 5. Decode the packed plaintext with a strict, fail-closed codec.
return decodeCredential(plainBuf, plainLen, out) ? RecordLoad::Ok
                                                 : RecordLoad::Rejected;

Two details make this safe rather than merely sequential.

First: the constant-time compare

First, the constant-time compare. Imagine a combination lock that gave a little click (and took a hair longer to answer) each time you got a digit right: guessing it blind would stop being hopeless, because the lock itself keeps whispering “warmer, warmer.” An ordinary byte comparison leaks exactly that hint. “Constant-time” here means concrete: the comparison takes the same amount of work regardless of the data, so its duration tells an observer nothing about the secret. A naïve memcmp does the opposite: it returns the instant it finds the first differing byte. Feed it a guessed tag and the time it takes to say “no” reveals how many leading bytes you got right: a tag matching the first 3 bytes returns measurably later than one that’s wrong at byte 0. An attacker who can measure that turns tag forgery into a byte-at-a-time search, ~256 tries per byte instead of 2²⁵⁶ for the whole tag. The vault never uses memcmp on secret-dependent data; it uses a branch-free comparison that XOR-accumulates every byte difference into one value and only checks that value at the very end (same number of operations whether the tag matches on byte 0 or byte 31):

// The vault calls Mbed TLS's mbedtls_ct_memcmp; this is the idea it implements:
bool constantTimeEqual(const uint8_t* a, const uint8_t* b, size_t len) {
    volatile uint8_t diff = 0;            // 'volatile' stops the optimizer
    for (size_t i = 0; i < len; i++)      // always touch EVERY byte
        diff |= a[i] ^ b[i];
    return diff == 0;                     // one check, at the very end
}

The vault doesn’t hand-write that loop: it calls Mbed TLS’s mbedtls_ct_memcmp, the library’s constant-time comparison primitive, which does exactly this. If you’ve never seen why this matters, Coda Hale’s A Lesson In Timing Attacks is the classic five-minute explanation; BearSSL’s constant-time notes go deeper.

Second: fail-closed by design

Second, fail-closed. The record is wiped before anything is read, so there is no code path (not a bad size, not a bad version, not a MAC mismatch, not a decrypt failure, not a malformed record) that can leave a partially-populated credential in the caller’s buffer. The function either returns Ok with a complete record or a refusal with nothing. It even keeps two refusals apart: Rejected means the stored bytes were read and refused, Unreadable means the check itself could not run (a busy buffer, a crypto resource failure), which says nothing about what is on flash.

What the tag really binds: slot, type, and freshness

A tag over ver ‖ iv ‖ cipher proves the ciphertext is genuine, but it says nothing about three things the format also needs to promise: which slot a file belongs to, what kind of record it is, and how recent it is. An attacker with raw flash write (a programmer or the debug port) but no PIN can turn each silence into an attack, and each maps to something mundane: dropping a letter in the wrong mailbox (wrong slot), relabeling a box so it passes for another kind (wrong type), or sliding last month’s receipt back in as if it were today’s (a stale revision):

Three gaps a ciphertext-only tag leaves open

Binding the missing context into the tag

The fix binds the missing context into the tag itself. This is exactly the role of associated data in an AEAD scheme (context that must be authenticated but not encrypted), except here it’s folded directly into the encrypt-then-MAC tag rather than passed to a single-pass cipher. The 8-byte prefix is centralized in one place, so every record module (and the key-rotation path) computes it bit-identically. slotId is a little-endian uint16, so every slot on the largest-capacity board gets its own authenticated value:

// ver(1) ‖ recordType(1) ‖ slotId(2, LE) ‖ generation(4, LE)
inline size_t writeEnvelopeContext(uint8_t* out,
                                   const EnvelopeContext& context) noexcept {
    out[0] = kEnvelopeVersion;                   // 0x01, unchanged on disk
    out[1] = std::to_underlying(context.type);   // Credential / Totp / ...
    out[2] =  context.slot       & 0xFF;         // the slot this record is,
    out[3] = (context.slot >> 8) & 0xFF;         //   little-endian u16
    out[4] =  context.generation        & 0xFF;  // per-slot freshness counter,
    out[5] = (context.generation >> 8)  & 0xFF;  //   little-endian u32
    out[6] = (context.generation >> 16) & 0xFF;
    out[7] = (context.generation >> 24) & 0xFF;
    return kEnvelopeContextSize;                 // 8
}

So a relocated file carries the wrong slotId, a retyped file the wrong recordType, and a rolled-back file an old generation. In each case the tag the firmware recomputes no longer matches the one on disk, so the read fails closed before a single byte is decrypted. It’s the same verify-before-decrypt gate, guarding three more promises:

The root of trust: authenticating meta.bin

Every check so far has leaned on something already being trustworthy: the keys, the freshness counters. That trust has to bottom out somewhere: in a root of trust, the one piece you don’t get to question, because if it were forged everything built on top would inherit the lie. Here that piece is meta.bin.

The generation counters have to live somewhere, and that somewhere has to be tamper-evident: otherwise an attacker would simply lower a counter to make a stale file look current. They live in meta.bin, the small record the device reads first, and it is two authenticated halves with a tag each.

The reason for two halves is that the PIN does not produce the record keys directly. PBKDF2 turns it into a key-encryption key (KEK), and the KEK unwraps a random 32-byte vault key that every record is keyed to. The first half holds what the secret alone has to open: the KDF salt and work factor, the PIN verifier, the wrapped vault key, and a tag under a KEK-derived key. Only an operation that holds the secret may replace it.

The second half is what any unlocked session may rewrite, which is what lets an ordinary save bump a generation counter without asking for the PIN again: the HMAC salt, the state of a key rotation, and a per-slot generation table for credentials and for TOTP entries, sealed by a tag under a key derived from the vault key.

There are two tags because there are two writers. One tag under a PIN-derived key would make every save re-run PBKDF2 (about 1.55 s on an ESP32-S3); one tag under a vault-key-derived key would mean unwrapping the vault key before anything was authenticated, a decrypt-before-verify on the wrap. So each half is sealed by a key its legitimate writer holds.

The unlock sequence becomes a careful ladder: nothing in the file is trusted until a tag checks out, and a wrong PIN derives a different KEK, so the wrap tag and the PIN verifier both miss at once.

Step two has to run before anything is authenticated, so the stored work factor reaches PBKDF2 unverified. The parse range-checks it, so a tampered record can neither stall the device past its watchdog nor talk it into a weak derivation, and editing it cannot forge anything: the verifier only reproduces at the count the vault was provisioned with.

The format byte does not move during development. It stays 0x01 while the layout changes, because before release the only deployment path is to erase the flash and re-provision, so a device only ever meets the current layout. Parsing is strict on that byte, so a foreign or older record fails closed and the vault is re-provisioned. There is no migration and no dual-read. (The device isn’t in production, so there’s no real data to migrate.)

What a PIN change costs

Wrapping the vault key is what makes a PIN change cheap. It rewrites the 154-byte first half inside one atomic meta.bin write, and every record on flash stays exactly as it was. Without the wrap, a PIN change re-encrypts the whole vault, needs roughly twice the vault’s space free, and so cannot complete on a nearly full device.

It has a price, and the project lists it first among its accepted risks. The vault key never changes unless you run the explicit Re-encrypt vault action, so a PIN change no longer revokes a key. A retired PIN plus any copy of meta.bin taken before the change unwraps the same vault key, and with it every credential written afterwards. That needs read access only, no flash write; on the hardened builds the wrap is device-bound, so it also needs the original chip. The same old meta.bin, written back with raw flash access, makes the retired PIN open the current vault and brings back the work factor it was derived with.

The remedy is that separate re-encrypt action: it walks every record under a new vault key, one committed step at a time so a power cut resumes it, and it is the one to use when a PIN may have leaked. It is the split LUKS and VeraCrypt make too: the passphrase wraps a volume key, and re-keying the volume is a separate, slower operation you choose.

How do you make anti-rollback crash-safe?

Selective rollback is a replay attack (the attacker re-presents an authentic-but-stale file), and the standard defense is a freshness value: a monotonic counter the verifier expects to only ever increase, so a replayed older record fails the check. But a freshness counter is only as good as its update story. Every mutation (add, edit, or delete) bumps the slot’s generation, and the record is written again under the new value. That creates a torn-write hazard: lose power between writing the record (under generation N+1) and writing meta.bin (which records N+1), and the two disagree. Resolve that wrong and you either brick a valid slot or quietly re-open the rollback you just closed.

The fix is to pick one single, indivisible moment that “counts,” like the signature on a contract: before the pen lifts nothing is binding, after it everything is. The firmware makes the meta.bin swap that moment (written to a temp file, then atomically renamed into place, so a reader always sees the old meta.bin or the new one, never a torn half-write) and recovers deterministically around it:

An append that closed is on flash, but whether it is live is decided by meta.bin alone: a slot’s live entry is the one whose generation matches the authenticated table. Lose power before the commit and the new entry carries a generation meta.bin never reached, so it is garbage and the slot keeps its previous record. Lose power after the commit and before the index write, and the index row is stale; the segment’s own tag check catches that and the row is rebuilt from the log. Each time meta.bin is authenticated, the store also re-appends the committed entry on top of any orphan, so presence, counts and the compaction agree with what readers trust. Compaction copies one segment’s live entries into a .tmp twin and renames it over the segment, so a segment is never absent. No window bricks a slot or silently re-opens rollback, and those interruptions have their own native tests. A delete appends a tombstone and bumps the generation in the same commit, so a deleted entry can’t be resurrected by replaying its old bytes.

The honest boundary: open vs _secure

Binding generation closes selective rollback: reverting one record while the rest of the vault moves on. It does not close a full snapshot rollback: revert the entire vault (meta.bin and every record together) to an earlier, internally consistent state, and the counters revert with it, so nothing looks out of place. On the open (developer-flashable) builds nothing detects it. The hardened _secure builds raise the bar without closing it: Flash Encryption and Secure Boot v2 stop an attacker from forging a new, older-looking state, but someone with physical access can still write back an encrypted image they captured from the same device earlier. True monotonic anti-rollback needs a hardware monotonic counter, and the chip’s one-time eFuse bits are no place for state that changes this often.

I’d rather state that boundary plainly than oversell it. The generation counter is defense in depth against the far more practical selective attack; the whole-vault time-warp stays a documented residual risk on every build, bounded on the hardened ones by flash encryption and physical access. The wrapped vault key gave it teeth, too: as the cost of a PIN change shows, writing back nothing but an older meta.bin brings back a retired PIN.

Does encrypt-then-MAC need separate keys?

Yes. The security argument for encrypt-then-MAC assumes the encryption key and the authentication key are independent; reusing one key for both jobs voids the guarantee and invites cross-protocol mischief, so the vault derives one sub-key to encrypt and another to MAC from the same vault key, each under its own domain-separation label. The PIN-derived KEK gets the same treatment for its own jobs.

It is the same instinct that says your house key, car key and mailbox key should be three different keys, and it follows the long-standing key-separation guidance; NIST SP 800-57 Part 1 puts it plainly: “a single key should be used for only one purpose”:

// The PIN-derived KEK opens the vault; the random vault key (VK) keys the records.
//   pinVerifier = HMAC(KEK, "kleidos-pin")              -> unlock check
//   wrapEnc     = HMAC(KEK, "kleidos-wrap-enc")         -> unwraps the VK
//   wrapMac     = HMAC(KEK, "kleidos-wrap-mac")         -> tags meta.bin's KEK half
//   encKey      = HMAC(VK,  "kleidos-enc")              -> AES-256-CBC key
//   macKey      = HMAC(VK,  "kleidos-mac" || hmacSalt)  -> record HMAC key
//   metaMac     = HMAC(VK,  "kleidos-meta-mac")         -> tags meta.bin's VK half
bool ok = deriveLabeled(vaultKey, kEncKeyLabel, out.enc.data(), out.enc.size());
ok = ok && deriveMacKey(vaultKey, hmacSalt, out.mac);  // label || hmacSalt
ok = ok && deriveLabeled(vaultKey, kMetaMacKeyLabel,
                         out.metaMac.data(), out.metaMac.size());

How do you check a PIN without storing it?

The PIN verifier is how the device checks the PIN without storing it: unlock derives the KEK from the entered PIN, computes the verifier, and compares it, again in constant time, against the stored value, once the wrap tag has already verified. A wrong PIN simply produces a different verifier, with no hint about how wrong it was. (The verifier sits in the first half of meta.bin, beside the salt; the PIN itself is never written anywhere.)

The point of the split is that each key can do exactly one thing. If the same key both encrypted files and authenticated them, a clever attacker could try to make ciphertext and tags interact, and the clean security proof for encrypt-then-MAC, which assumes the two keys are independent, would simply no longer apply. Keeping them separate means a compromise or misuse of one capability can’t borrow another:

Defense in depth: constant-time padding + a fail-closed codec

Because the MAC is verified first, a tampered file never reaches the decryption code, which means the classic padding oracle is unreachable by construction. The padding check below is therefore defense in depth, not the primary defense: belt and suspenders for the case where authenticated-but-corrupt data still needs to be rejected cleanly.

The vault applies and checks PKCS#7 padding itself. AES runs through PSA with PSA_ALG_CBC_NO_PADDING: the firmware pads the plaintext before encrypting, and after decrypting (so only once the MAC has passed) it validates the padding in constant time and reports a single unified failure, so it leaks nothing through logs or timing regardless. The library’s own CBC-PKCS7 mode is never used, which is also why CVE-2025-59438, a padding-error timing leak in that mode, does not apply to the vault. (The 32-byte vault key is wrapped with no padding at all: it is exactly two blocks.)

// The last byte claims the pad length; fold every check into one mask.
const uint8_t padByte    = plainOut[cipherLen - 1];
uint8_t       padInvalid = 0;
padInvalid |= static_cast<uint8_t>(padByte == 0);             // length 0: illegal
padInvalid |= static_cast<uint8_t>(padByte > kAesBlockSize);  // > a block: illegal
for (size_t i = 0; i < kAesBlockSize; i++) {
    const uint8_t mask = (i < padByte) ? 0xFF : 0x00;         // examine the whole block
    padInvalid |= static_cast<uint8_t>((plainOut[cipherLen - 1 - i] ^ padByte) & mask);
}
if (padInvalid != 0) {   // the caller logs ONE message for corruption AND bad padding
    mbedtls_platform_zeroize(plainOut, cipherLen);
    return false;
}
*plainLen = cipherLen - padByte;

The decrypted plaintext is then handed to an in-house binary codec, not a general-purpose parser. The decrypted bytes are the most sensitive range in the whole product, and I don’t want a JSON or CBOR library (with its surface area, its allocations, its surprises) anywhere near them. The decoder is a forward-only cursor where every read is bounds-checked before it copies, every string length is rejected if it exceeds the field’s compile-time cap, and any trailing garbage fails the record:

// need(n): are n more bytes available, without integer-overflow wraparound?
bool need(size_t n) const noexcept { return off_ + n <= len_ && off_ + n >= off_; }

// Read a length-prefixed string: reject len > field-capacity BEFORE copying.
template <size_t N>
bool readStrBody(InplaceString<N>& dst, size_t len) noexcept {
    if (len > N || !need(len)) return false;   // fail closed, no partial copy
    std::memcpy(dst.data(), p_ + off_, len);
    dst.data()[len] = '\0';                     // NUL-terminate the destination
    dst.resyncLength();
    off_ += len;
    return true;
}

Why CBC+HMAC and not AES-GCM?

A fair question. The modern default for authenticated encryption is an AEAD construction like AES-GCM, which fuses encryption and authentication into one primitive and is harder to assemble incorrectly. If I were starting a greenfield protocol, GCM (or ChaCha20-Poly1305) would be the obvious pick.

The vault uses encrypt-then-MAC with AES-256-CBC and HMAC-SHA256 for reasons that are about this device, not about the primitives. CBC with HMAC has no catastrophic failure mode if an IV ever repeats: a repeated IV leaks that two records share their first blocks, not a key, while a repeated GCM nonce gives away the authentication key. AES and SHA-256 are both hardware-accelerated on the ESP32. And the hard part of this format, freshness, is a state problem that associated data would not solve: an AEAD would carry the same type ‖ slot ‖ generation in its associated data, with a riskier primitive underneath. Encrypt-then-MAC is the generically secure composition, so building AEAD out of CBC+HMAC this way is sound; it’s how IPsec (in its standard configuration) and KDBX 4 do it too.

There used to be a third reason, byte-identical output from a host build whose unit tests ran against the legacy Mbed TLS API and a device where Mbed TLS 4.0’s PSA Crypto API is the only public path. That one is gone: the host tests now link Mbed TLS 4 and TF-PSA-Crypto too, so both sides run the same PSA backend and there is no second API to keep in step. The versions differ by a patch release (the device’s ESP-IDF 6.0.3 ships Mbed TLS 4.1.1 with TF-PSA-Crypto 1.1.1; the host builds Mbed TLS 4.1.0 with TF-PSA-Crypto 1.1.0), and what anchors their output is the standards, not the version: both run the production primitives against the same published known-answer vectors (PBKDF2-HMAC-SHA256 against RFC 7914 §11, HMAC-SHA256 against RFC 4231 Test Case 1), and the device also checks AES-256-CBC against NIST SP 800-38A.

One footnote on the implementation: PSA’s transition guide suggests psa_mac_verify over “compute a tag, then mbedtls_ct_memcmp.” The record path still computes and compares, with one tag function shared by the write and the read; the encrypted export streams its chunks through psa_mac_verify. Both comparisons are constant-time.

How does the vault list credentials without decrypting them all?

The list index is a set of encrypted segments, idx_NN.bin, one per 32 credential slots, each in the exact same [ver][iv][hmacTag][cipher] envelope. They cache only the non-secret metadata a list view needs: id, name, username, brand, the domain taken from the URL, group, order, modification time and two flags (favorite, has 2FA). Never the password, the full URL, notes, or TOTP secret. Listing therefore costs one read and one decrypt per 32 slots, not one per credential.

That falls out of treating every artifact as an independent envelope. Decrypting every credential just to draw a list would be slow and would needlessly expose every secret in RAM; the index sidesteps both. Each segment binds its own number as slotId and, as generation, the sum of the credential counters of the slots it caches, so an older copy of a segment fails its tag like any rolled-back record. Splitting it also keeps the working set fixed: a single index file needed RAM in proportion to the credential count, which a board without PSRAM ran out of long before its nominal capacity.

Fail closed, by construction

The cipher isn’t what makes this vault trustworthy at rest; the order of operations is. Put plainly: never trust a file until its seal checks out, and when in doubt, hand back nothing. Authenticate the slot, type, freshness, IV, and ciphertext with a separate key; verify that tag in constant time before a single byte is decrypted; authenticate the metadata that holds the freshness counters; wipe everything on the way out; and let every error path converge on the same answer: nothing. Get those right and AES-256 is almost an implementation detail.

There’s one thing this format doesn’t solve, though. All of it protects the file, but the key that unlocks the vault still ultimately comes from a short PIN, and a short PIN has very little entropy. On the device that’s fine: a brute-force guard locks out and eventually wipes the vault after a handful of wrong PINs, so online guessing dies quickly. The problem is offline. If someone desolders the flash and copies the ciphertext, the lockout never runs: they can derive keys from PIN guesses on a GPU, with no device in the loop to stop them, and a 4-digit keyspace falls in a fraction of a second. (Production flash encryption raises that bar, but the file format shouldn’t have to depend on it.) Closing that gap needs a different trick: one that mixes a secret only the original chip can produce into the key, so the exfiltrated ciphertext is useless on any other hardware. That’s the next post.
