Mastering Mutual TLS (mTLS) with Nginx: A Deep Dive

# =============================================================
# OpenSSL Configuration for mTLS Certificate Authority
# =============================================================

[ ca ]
default_ca = CA_default

[ CA_default ]
# Directory structure
dir               = /etc/nginx/pki
database          = $dir/index.txt
new_certs_dir     = $dir/newcerts
certificate       = $dir/ca/ca.crt
serial            = $dir/serial
private_key       = $dir/private/ca.key
crlnumber         = $dir/crlnumber
crl               = $dir/crl/ca.crl

# Certificate defaults
default_days      = 365          # Client certs valid 1 year
default_crl_days  = 30           # CRL valid 30 days
default_md        = sha256       # Use SHA-256
preserve          = no
policy            = policy_loose
copy_extensions   = copy         # Copy SANs from CSR
# SECURITY WARNING: copy_extensions=copy copies ALL extensions from the CSR.
# This is safe only when you trust the CSR generator. A malicious CSR could
# include basicConstraints: CA:TRUE to create a subordinate CA.
# Use copy_extensions=none or explicitly filter extensions for untrusted CSRs.

[ policy_loose ]
countryName             = optional
stateOrProvinceName     = optional
localityName            = optional
organizationName        = optional
organizationalUnitName  = optional
commonName              = supplied
emailAddress            = optional

# =============================================================
# CA Certificate Request Settings
# =============================================================
[ req ]
default_bits        = 4096
distinguished_name  = req_distinguished_name
string_mask         = utf8only
default_md          = sha256
x509_extensions     = v3_ca
prompt              = no

[ req_distinguished_name ]
C                   = ES
ST                  = Valencia
L                   = Valencia
O                   = JMRP-IO-LAB
OU                  = Infrastructure Security
CN                  = JMRP-IO-LAB Root CA

# =============================================================
# Certificate Extensions
# =============================================================

# For the CA certificate itself
[ v3_ca ]
subjectKeyIdentifier    = hash
authorityKeyIdentifier  = keyid:always,issuer
basicConstraints        = critical, CA:TRUE
keyUsage                = critical, digitalSignature, cRLSign, keyCertSign

# For client certificates
[ v3_client ]
subjectKeyIdentifier    = hash
authorityKeyIdentifier  = keyid,issuer
basicConstraints        = critical, CA:FALSE
keyUsage                = critical, nonRepudiation, digitalSignature, keyEncipherment
extendedKeyUsage        = clientAuth

server {
    listen 443 ssl;
    listen [::]:443 ssl;
    http2 on;
    server_name secure.example.com;

    # =================================================
    # Server TLS Configuration
    # =================================================
    ssl_certificate     /etc/ssl/certs/secure.example.com.crt;
    ssl_certificate_key /etc/ssl/private/secure.example.com.key;

    # =================================================
    # Client Certificate (mTLS) Configuration
    # =================================================

    # Path to your Certificate Authority
    ssl_client_certificate /etc/nginx/pki/ca/ca.crt;

    # Require valid client certificate
    ssl_verify_client on;

    # Verify up to 2 levels in the certificate chain
    ssl_verify_depth 2;

    # Optional: Certificate Revocation List
    # ssl_crl /etc/nginx/pki/crl/ca.crl;

    # =================================================
    # TLS Protocol Configuration
    # =================================================
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305;
    ssl_prefer_server_ciphers on;

    # Performance: SSL Session Caching
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 1d;
    ssl_session_tickets off;

    # =================================================
    # Logging (Include Client DN for Debugging)
    # =================================================
    access_log /var/log/nginx/secure.access.log combined;
    error_log /var/log/nginx/secure.error.log warn;

    # =================================================
    # Application
    # =================================================
    location / {
        # First, clear any client-provided values to prevent spoofing
        proxy_set_header X-Client-DN "";
        proxy_set_header X-Client-Verify "";
        proxy_set_header X-Client-Fingerprint "";

        # Then set authenticated values from Nginx's SSL module
        # Backend should only trust these when requests come directly from Nginx
        proxy_set_header X-Client-DN $ssl_client_s_dn;
        proxy_set_header X-Client-Verify $ssl_client_verify;
        proxy_set_header X-Client-Fingerprint $ssl_client_fingerprint;

        proxy_pass http://127.0.0.1:8080;
    }
}

# Only allow TLS 1.2 and 1.3
ssl_protocols TLSv1.2 TLSv1.3;

# Strong cipher suites (ECDHE for forward secrecy, GCM for AEAD)
ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305;

# Server chooses the cipher (prevents downgrade attacks)
ssl_prefer_server_ciphers on;

# Session resumption for performance
ssl_session_cache shared:SSL:10m;
ssl_session_timeout 1d;

# Disable session tickets (more secure, less memory)
ssl_session_tickets off;

# Diffie-Hellman parameters for non-ECDHE (if needed)
# Generate with: openssl dhparam -out /etc/nginx/dhparam.pem 4096
ssl_dhparam /etc/nginx/dhparam.pem;

# Place this OUTSIDE the server block (in nginx.conf or included file)

# Map client DN to access permission
map $ssl_client_s_dn $mtls_access_allowed {
    default 0;

    # Allowed certificates by CN
    "CN=iphone-jmrp"      1;
    "CN=macbook-jmrp"     1;
    "CN=ipad-home"        1;

    # Pattern matching with regex
    ~"CN=admin-.*"        1;    # All admin-* certificates
}

server {
    # ... SSL configuration ...

    location / {
        # Verify certificate is valid (handled by ssl_verify_client on)
        # Then check our custom authorization
        if ($mtls_access_allowed = 0) {
            return 403 "Valid certificate, but not authorized for this resource.";
        }

        proxy_pass http://backend;
    }
}

http {
    # ...

    # 1. Map the verification status to a rate-limit key
    map $ssl_client_verify $limit_req_whitelist {
        "SUCCESS" "";                  # If verified, key is empty (no limit)
        default   $binary_remote_addr; # Otherwise, limit by IP
    }

    # 2. Define the zone using the map variable
    # If $limit_req_whitelist is empty, the request is not counted!
    limit_req_zone $limit_req_whitelist zone=req_limit_per_ip:10m rate=5r/s;

    server {
        # IMPORTANT: To allow unauthenticated clients to reach this logic,
        # you must set 'ssl_verify_client optional' instead of 'on'.
        # If set to 'on', Nginx rejects the handshake before the rate limiter runs.
        ssl_verify_client optional;

        # 3. Apply the limit
        limit_req zone=req_limit_per_ip burst=10 nodelay;

        # ...
    }
}

# Enable CRL checking
ssl_crl /etc/nginx/pki/crl/ca.crl;

0 3 * * * /usr/local/bin/mtls-renew.sh >> /var/log/mtls-renew.log 2>&1
