Securing Nginx with Client Certificates (mTLS)

Implementing Mutual TLS (mTLS) is one of the most robust ways to secure private web services. Unlike standard password authentication, mTLS requires the client (your browser/device) to present a valid certificate signed by your own Certificate Authority (CA).

If the client doesn’t have the certificate, the Nginx server rejects the connection entirely—often before even serving the login page. This is perfect for securing private administration panels, NAS interfaces, or internal tools like the one running on secure.example.com.

In this guide, I’ll walk you through creating a bespoke Certificate Authority, generating client certificates, configuring Nginx, and handling advanced scenarios like revoking access for lost devices or restricting specific users. You can find more deep-dive tutorials from providers like Smallstep’s Hello mTLS..

How it Works

Before diving into the commands, let’s look at the handshake process.

The Full Logic Flow

Strategies and Use Cases

Why go through the trouble of managing certificates? It separates the concepts of authentication and authorization at the infrastructure level.

1. Zero Trust Access: Even if an attacker steals your password, they can’t access the site without the physical file (the private key/certificate) installed on their device.
2. Reduction of Attack Surface: “Script kiddies” and bots scanning for vulnerabilities (like open WordPress login pages) will simply receive a 400 Bad Request or connection reset. They won’t even see the application.
3. Seamless Experience: Once installed, the browser handles the handshake automatically. No need to type 2FA codes every time.

Prerequisites

• A Linux server (Debian/Ubuntu/CentOS) with Nginx installed.
• Access to the terminal.
• The openssl command-line tool installed (standard on almost all Linux distros).

Step 1: Create Your Certificate Authority (CA)

First, we need to become our own Authority. To ensure we can properly revoke certificates later, we need a consistent configuration and database.

Create a directory to store your keys safely and set up the CA database:

mkdir -p /etc/nginx/client-certs && cd /etc/nginx/client-certs

mkdir -p newcerts && touch index.txt && echo 1000 > serial

1. Create a Minimal openssl.cnf

Create a file named openssl.cnf in this directory. This file ensures that openssl ca (used for signing and revocation) knows where your files are.

[ ca ]
default_ca = CA_default
[ CA_default ]
dir             = .
database        = $dir/index.txt
new_certs_dir   = $dir/newcerts
certificate     = $dir/ca.crt
serial          = $dir/serial
private_key     = $dir/ca.key
default_days    = 365
default_crl_days= 30
default_md      = sha256
policy          = policy_loose
copy_extensions = copy
[ policy_loose ]
countryName             = optional
stateOrProvinceName     = optional
localityName            = optional
organizationName        = optional
organizationalUnitName  = optional
commonName              = supplied
emailAddress            = optional
[ req ]
distinguished_name = req_distinguished_name
prompt             = no
[ req_distinguished_name ]
C  = ES
ST = Valencia
L  = Valencia
O  = JMRP-IO-LAB
OU = IT Services
CN = JMRP-IO-LAB Root CA

2. Generate the CA Key and Certificate

Now generate the root CA, which consists of a private key (ca.key) and a public certificate (ca.crt).

openssl req -new -x509 -nodes -days 3650 -out ca.crt -keyout ca.key -config openssl.cnf

-----BEGIN PRIVATE KEY-----
(Your unique, long, private key text will be here)
...
-----END PRIVATE KEY-----

-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----

You can verify your new CA certificate content:

openssl x509 -in ca.crt -text -noout

Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number:
            1a:c9:b8:c1:74:7b:93:ff:b7:be:e1:fb:b5:2e:cd:b1:34:b5:dd:ce
        Signature Algorithm: sha256WithRSAEncryption
        Issuer: C = ES, ST = Valencia, L = Valencia, O = JMRP-IO-LAB, OU = IT Services, CN = JMRP-IO-LAB Root CA
        Validity
            Not Before: Dec 18 00:59:30 2025 GMT
            Not After : Dec 16 00:59:30 2035 GMT
        Subject: C = ES, ST = Valencia, L = Valencia, O = JMRP-IO-LAB, OU = IT Services, CN = JMRP-IO-LAB Root CA
        Subject Public Key Info:
            Public Key Algorithm: rsaEncryption
                Public-Key: (4096 bit)
                Modulus:
                    00:ad:9e:5a:cf:ea:b4:d8:68:1e:48:87:64:c5:f9:
                    ...
                Exponent: 65537 (0x10001)
        X509v3 extensions:
            X509v3 Subject Key Identifier:
                C4:CD:09:55:A1:CB:27:C1:00:B6:17:E3:AE:B5:65:1B:31:3A:06:CC
            X509v3 Authority Key Identifier:
                C4:CD:09:55:A1:CB:27:C1:00:B6:17:E3:AE:B5:65:1B:31:3A:06:CC
            X509v3 Basic Constraints: critical
                CA:TRUE
    Signature Algorithm: sha256WithRSAEncryption
    Signature Value:
        9c:38:37:51:d7:22:a8:d9:a7:57:d4:88:04:40:16:33:3f:52:
        ...

Step 2: Generate Client Certificates

Now let’s create a certificate for a specific user.

1. Generate User Private Key and CSR

openssl req -new -newkey rsa:2048 -nodes -keyout user.key -out user.csr -subj "/CN=jmrp.io-client"

2. Sign the CSR with your CA

openssl ca -config openssl.cnf -batch -in user.csr -out user.crt

Using configuration from openssl.cnf
Check that the request matches the signature
Signature ok
The Subject's Distinguished Name is as follows
commonName            :ASN.1 12:'jmrp.io-client'
Certificate is to be certified until Dec 18 00:59:34 2026 GMT (365 days)

Write out database with 1 new entries
Database updated

This process creates user.key and user.crt.

-----BEGIN PRIVATE KEY-----
(A different unique, long, private key text will be here)
...
-----END PRIVATE KEY-----

-----BEGIN CERTIFICATE-----
(The text for the user's certificate will be here. It will be
signed by your "JMRP-IO-LAB Root CA".)
...
-----END CERTIFICATE-----

3. Convert to PKCS#12 (.p12)

openssl pkcs12 -export -out user.p12 -inkey user.key -in user.crt -certfile ca.crt

You will be asked to create an export password. This protects the file itself.

Step 3: Configure Nginx

With the certificates generated, we need to tell Server Block to trust any client signed by our CA. All the directives used here are part of the Nginx SSL Module.

Edit your site configuration:

server {
    server_name secure.example.com;
    listen 443 ssl;

    # ... other SSL settings ...

    # ---------------------------------------------
    # Client Certificate Verification
    # ---------------------------------------------

    # Path to the CA certificate we created in Step 1
    ssl_client_certificate /etc/nginx/client-certs/ca.crt;

    # Enable verification
    ssl_verify_client on;

    # Optional: Verify chain depth
    ssl_verify_depth 2;

    location / {
        # ... proxy settings ...
    }
}

Test and Reload

Before applying, always check the configuration syntax:

sudo nginx -t

sudo systemctl reload nginx

Now, if you try to visit https://secure.example.com from a device without the certificate, Nginx will return a 400 Bad Request (No required SSL certificate was sent). The gate is closed!

Step 4: Advanced Access Control

By default, any client with a valid certificate signed by your CA can access the site. But what if you have multiple services and want to restrict “John” to Service A and “Alice” to Service B?

You can use the Common Name (CN) from the certificate to authorize specific users.

Open your Nginx config again. We will use the map directive (place this outside the server block, usually in nginx.conf or at the top of your site config):

# Map the client certificate DN (Distinguished Name) to an access variable
map $ssl_client_s_dn $ssl_access_allowed {
    default 0;
    # Format: /CN=CommonName
    "/CN=iphone-admin" 1;
    "/CN=laptop-work" 1;
    "/CN=ipad-home" 1;
}

Then, inside your server block:

server {
    # ... ssl configuration ...

    location / {
        # First, ensure the cert is valid (already handled by ssl_verify_client)

        # Then check our custom map
        if ($ssl_access_allowed = 0) {
            return 403 "Forbidden: You have a valid certificate, but are not authorized for this resource.";
        }

        # ... proxy_pass ...
    }
}

Now, creating a certificate for a friend won’t automatically grant them access to this specific site unless you add their CN to the whitelist.

Step 5: Revoking Certificates (CRL)

What happens if you lose your phone? The certificate on it is still valid for a year. You need a way to revoke it effectively. This is done using a Certificate Revocation List (CRL).

1. Revoke a Certificate

Let’s say user.crt (from the lost phone) needs to be revoked.

openssl ca -config openssl.cnf -revoke user.crt

Using configuration from openssl.cnf
Revoking Certificate 1000.
Data Base Updated

2. Generate the CRL File

After revoking, you must generate the list itself so Nginx can read it:

openssl ca -config openssl.cnf -gencrl -out crl.pem

Output: (No output usually means success)

3. Configure Nginx to Check the CRL

Update your Nginx server block to check this list:

# inside server block
ssl_crl /etc/nginx/client-certs/crl.pem;

Reload Nginx. Now, even if the “lost phone” presents its certificate, Nginx sees it in the CRL and blocks access.

Step 6: Installing Certificates on Clients

Now you need to install the .p12 file (generated in Step 2.3) onto your devices.

Troubleshooting

Here are the most common issues you might face.

400 Bad Request (No required SSL certificate…)

• Cause: The browser didn’t send a certificate.
• Fix: Ensure the .p12 is installed. Restart the browser completely. Try Incognito/Private mode, as browsers sometimes stick to a “no-cert” session state.

400 Bad Request (The SSL certificate error…)

• Cause: The certificate exists but Nginx doesn’t like it.
• Fix: Nginx might not trust the CA. Check ssl_client_certificate. Ensure the chain is correct.

403 Forbidden

• Cause: The certificate was accepted, but access was denied later.
• Fix:
  • If using CRL: The cert might be revoked.
  • If using map (Access Control): The CN might not match. Check Nginx error logs (/var/log/nginx/error.log) to see the actual $ssl_client_s_dn being received.

”Certificate Connection” Dialog loop

• Cause: On macOS/iOS, sometimes the system prompts repeatedly.
• Fix: Ensure the CA certificate is also trusted in the Keychain (though technically not required for client auth, it helps the OS validate the chain).

Conclusion

You have now implemented military-grade authentication for your home server services. By combining Nginx’s ssl_verify_client with your own Certificate Authority, you’ve ensured that only trusted devices can even see your login screen.

This setup is ideal for exposing sensitive services like TrueNAS, Home Assistant, or private Wikis to the internet without relying solely on their built-in login forms.
